18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line

Name: 18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line
Brand: Sunswell
Price: 20000 USD

Buy cheap 18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line product

Warranty of core components : 1 Year

Application : Beverage, Hot Juice/Tea

Suitable Can Volumen : 250~500ml

Packaging Material : Wood

Core Components : Motor, PLC, Bearing

Brand Name : Sunswell

Model Number : YDGF

Certification : ISO,CE

Warranty : 1 Year

After Warranty Service : Video technical support, Online support, Field maintenance

Filling Accuracy : ±2%

MOQ : 1 Set

Driven Type : Electric

Dimension(L*W*H) : 2400x1650x2500mm

Place of Origin : China

Machine Body Material : SS304

Supply Ability : 50 Set/Sets per Year

Delivery Time : 50 days

Machinery Test Report : Provided

Packaging Type : CANS

Key Selling Points : Long Service Life, High accuracy

Packaging Details : wood case & carton packaging

Filling Material : Beer, Water, Juice, Carbonated Soft Drinks

Voltage : 220V, 380V, 400V, 415V, 460V

Price : USD 20000 per Set

Weight : 2500 KG

Payment Terms : L/C, T/T

Machinery Capacity : 2000-36000CPH

Filling Valve Material : SS304 or SS316L

Contact Now

18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line

Products Description

Filling & Seaming 2-in-1 for hot filling can

It is suitable for filling and seaming non-carbonated liquid such as water, juice, functional beverage, etc. It is equipped the
 advanced device, electrical equipment, and pneumatic control technology. It has the characteristics of filling reposefully, high speed, liquid level control, seaming reliably, frequency conversion timing, less material loss. It is the preferred equipment for beverage plants.

18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line

Working Procedure

Cans will be pushed into can holding platform one by one by feeding screw and star-wheel. Centering cup of filling valve will fall to can; the distance between filling valves and cans is sealed by springiness plastic ring. The movement of centering cup is generated by plastic idler wheel along curvilinear motion. After filled, valve will be closed and centering cup will rise from the can. Filled can will be sent to conveyor chain, then to seamer. Seamer will take lid, turn over the edge of can and turn the edge to finish the sealing action by the control of cam. After that can will be transferred to conveying system.

  	 			Model
 			Filling Heads
 			Capacity 500ml
 			Bottle Size
 			Power
 			Dimension(mm)
 			Weight(KG)

 			GF 12-4
 			12
 			4000BPH
 			330ml
 			1.8kw
 			2200*1800 * 2000
 			2500

 			GF 18-4
 			18
 			9000BPH
 			330ml
 			2.6kw
 			2500 * 1800 * 2300
 			3000

 			GF 20-4
 			20
 			12000BPH
 			330ml
 			3.8kw
 			2800 * 2100 * 2300
 			5000

 			GF 32-6
 			32
 			18000BPH
 			330ml
 			4.2kw
 			3500 * 2200 * 2300
 			6000

 			GF 40-8
 			40
 			24000BPH
 			330ml
 			7kw
 			4760 * 2080 * 2300
 			7000


Please send us your bottle size & required hourly output via inquiry, our engineer will recommend the most suitable model with exact quotation.

Details Images

18000CPH 200ml CSD Carbonated Soft Drink Canning Production Line

Can Infeed

Cans divide into fixed intervals through screw to can infeed dial wheel, then enter into filling machine. After filling, cans are tranported to the capping machine through the tank device. By two curling, capping is completed. Cans are sent into the can outfeed dial wheel and tranmitted to can outfeed belt, then sent to the next process (or equipment).

Filler

Filling machine components mainly consist of filling cylinder, turntable, filling valve, lifting devices, upper and lower distributor, star wheel device, screw transmission device and main liquid pipe, etc. Filling valve mainly consists of valve seat, spool, valve sleeve, middle sleeve, spring and air pipe, etc. The interior streamlined design ensures that there is no sanitary comer, built-in mechanical, stable and reliable performance, low maintenance costs.

Seamer

Can sealing machine mainly consists of the upper part of the machine, the lower part of the machine, under the cover device, motor drive, hydraulic system and other components.

Can Outfeed

Nylon wheel and conveyor belt cooperate output cans. Conveyor motor uses frequency control of motor speed, which keeps pace with the 2-1 machine.

Technical Parameters

Capacity	36,000BPH (250ml)
Filling heads	60pcs
Seaming heads	6pcs
Filling method	Gravity Filling

Company Profile

1.About us

Set up in 2008, Sunswell leads the market in the field of liquid bottling, blow molding, labeling, packaging machinery and process
 technology for water, tea, juice, carbonated drinks, energy drinks, liquid, beer, edible oil, dairy and daily care products, etc.

 We can customize liquid food production lines according to customers' demand. Every customer is the result of our proven
 experience and innovation. We continually focus on providing customers with advanced technology, engineering and facility that are
 designed with one mottos in mind: ensure you to reach business goals with most optimized planning.

 Why choose us?
 (1)A to Z turnkey plant provider
 (2)Fully automatic or economic solution optional
 (3)10+ years of global market experience
 (4)Serve customers over 50 countries and regions worldwide

 Office & Factory & Workshop

Spare Parts / Maintenance, Installation & Commissioning / Training

No matter whether you're a newcomer or a sectoral expert – we have the specialists who can provide the comprehensively can-do support you need for planning a new facility in terms of not only actual beverage production, but also filling, packaging,utilities and logistics. In closely responsive consultation with you, from a multiplicity of possible options, we select the technologically and commercially most effective variant, handle the design and planning work, and bring the project to a successful conclusion at your chosen location. Sunswell is not only the consultant here, but also takes responsibility for executing the entire project.Any more questions, pls feel free to contact me !
